An Odd Ball in Space: OSIRIS-REx Spacecraft Studies Asteroid Bennu Up Close

Bennu's surface is rockier than expected, creating challenges for the team whose mission is to scoop up a sample of pristine material and return it to Earth in 2023. (Image: NASA/Goddard/UA)

By Daniel Stolte, University Communications - March 19, 2019

When NASA's OSIRIS-REx spacecraft arrived at its destination, asteroid Bennu, on Dec. 3, it found a tiny world that in many respects looks like what the mission team had expected based on ground-based observations, but holds quite a few surprises, too. In a series of eight scientific papers published March 19 across several Nature Publishing Group journals, the members of the University of Arizona-led OSIRIS-REx mission present their first up-close observations of asteroid Bennu since the spacecraft's arrival.

While the spacecraft's observations confirmed many of the measurements obtained by ground-based observations, Bennu turns out to be a more challenging target than what the mission was originally designed for. Its surface is rougher and more varied in brightness than expected, prompting mission engineers and scientists to re-evaluate some of the approaches designed around the mission's primary goal: collecting a sample of surface material, or regolith, and returning it to Earth in 2023.

"Despite these newly found challenges, our team is confident that we will meet the science objectives," said Dante Lauretta, OSIRIS-REx principal investigator and professor of planetary science at the UA's Lunar and Planetary Laboratory. "The OSIRIS-REx team designed the mission with flexibility and capabilities to deal with the unknown, and we are prepared to answer the challenges Bennu has given us."

Coinciding with these publications, mission members presented some of the findings made by the spacecraft upon arrival at the asteroid at the 50thLunar and Planetary Sciences Conference in Houston on March 19.

The following provides the key findings published in those scientific papers whose principal authors are UA researchers – Dante Lauretta, Daniella DellaGiustina, Carl Hergenrother and Heather Enos, all of the UA's Lunar and Planetary Laboratory, or LPL. Josh Emery is an alumnus of the LPL.

One of the Darkest Objects in the Solar System with Rougher-Than-Expected Terrain

The OSIRIS-REx team developed its sampling strategy around what was known about Bennu when the mission was designed, promising plentiful patches of relatively smooth surface with gravel and pebbles less than 1 inch in size that expand over at least 55 yards (50 meters). Instead, the spacecraft observed only a small number of regions, each between 5.4 and 22 yards (5 and 20 m), that are devoid of large boulders that pose a hazard to the spacecraft when it touches down to collect its sample. Instead of having the equivalent of half a football field to navigate in, the spacecraft will have to operate within the confines of sampling sites that are half the size of a basketball court or smaller. High-resolution images made with the OSIRIS-REx camera suite, or OCAMS, designed and built at the LPL, reveal a surface packed with more than 200 boulders larger than 33 feet (10 m) in diameter and many more that are 3 feet (1 m) or larger. The largest boulder measures 63 yards (58 m) across. OCAMS measurements confirm that Bennu is one of the darkest objects in the solar system, reflecting only 4 percent of sunlight. One of the surprises turned out to be a larger-than-expected variability in surface albedo. In other words, Bennu's surface features vary greatly from one another with respect to their brightness. The high variability in albedo presents a challenge for the laser of the spacecraft's lidar system, designed to guide the sample acquisition approach.

References: Lauretta and DellaGiustina et al., “The unexpected surface of asteroid (101955) Bennu,” Nature; DellaGiustina and Emery et al., “The regolith of (101955) Bennu from OSIRIS-REx imaging and thermal analysis,” Nature Astronomy.

A Strange Rubble Pile

The asteroid has the spinning-top shape already evident in radar observations made in 1999 and 2005. Estimated to be between 100 million and 1 billion years old, the asteroid's surface is older than expected, but shows evidence of more recent activity. High-standing ridges run from Bennu’s north to south pole and appear to direct the flow of surface material. Features such as infill of large craters, fractured boulders and a deficiency in small impact craters hint at a dynamic surface with ongoing changes. Bennu is a rubble pile with a lot of void space, up to 60 percent total porosity, but its shape indicates that it has interior “stiffness”– enough internal friction or cohesion to allow the surface to crack.

References: Barnouin et al., “Shape of (101955) Bennu indicative of a rubble pile with internal stiffness,” Nature Geoscience; and Walsh et al., “Craters, boulders and regolith of (101955) Bennu indicative of an old and dynamic surface.” Nature Geoscience.

A Watery Past

Spectral data obtained with the OSIRIS-REx Visible and InfraRed Spectrometer, or OVIRS, confirm Bennu’s classification as a primitive carbonaceous chondrite and indicate that it most closely resembles aqueously altered CM chondrites. Hydrated minerals are ubiquitous across the surface of the asteroid. There is evidence for molecules that contain oxygen and hydrogen atoms bonded together, known as hydroxyls. The team suspects that these hydroxyl groups exist globally across the asteroid in water-bearing clay minerals, meaning that at some point, the rocky material interacted with water. While Bennu itself is too small to have ever hosted liquid water, the finding does indicate that liquid water was present at some time on Bennu's parent body, a much larger asteroid.

Reference: Hamilton et al. “Evidence for widespread hydrated minerals on asteroid (101955) Bennu.” Nature Astronomy.

Spinning Faster

Bennu’s rotation is accelerating steadily at about one second per 100 years. This is thought to be due to the so-called YORP effect, a phenomenon in which differences in reflectivity and temperature across an asteroid's surface result in a faster spinning rate over time, which in some cases can ultimately lead to an asteroid breaking apart. Because Bennu’s rotation rate has been changing, mission scientists infer that its surface slopes have been changing over the past million years.

In a surprise find, navigational images taken by the spacecraft upon arrival revealed particles in the vicinity of Bennu which will be investigated in more detail during the upcoming site selection campaign.

References: Hergenrother et al., “Operational environment and rotational acceleration of asteroid (101955) Bennu from OSIRIS-REx observations,” Nature Communications; and Scheeres et al., “The dynamic geophysical environment of (101955) Bennu based on OSIRIS-REx measurements,” Nature Astronomy.

In addition to the scientific reports listed above, Enos, the mission's deputy principal investigator, provided an overview paper aimed at the general public about the spacecraft's rendezvous with Bennu.

NASA's Goddard Space Flight Center in Greenbelt, Maryland, provides overall mission management, systems engineering, and the safety and mission assurance for OSIRIS-REx. Lauretta is the principal investigator, and the UA also leads the science team and the mission's science observation planning and data processing. Lockheed Martin Space Systems in Denver built the spacecraft and is providing flight operations. Goddard and KinetX Aerospace are responsible for navigating the OSIRIS-REx spacecraft. OSIRIS-REx is the third mission in NASA's New Frontiers Program. NASA's Marshall Space Flight Center in Huntsville, Alabama, manages the agency's New Frontiers Program for the Science Mission Directorate in Washington.
